Astra

N101BGE-L21 10.1 inch 16:9 High Resolution 1024 x 600 Laptop Screens LED TFT Panels

N101BGE-L21 10.1 inch 16:9 High Resolution 1024 x 600 Laptop Screens LED TFT Panels

$67.72 USD
$67.72 USD
Распродажа Продано
Сумма налога включена. Стоимость доставки рассчитывается при оформлении заказа.
1. High quality replacement screen panel.
2. High resolution 1024 x 600 pixel.
3. 16:9 aspect ratio standard screen.
4. 10.1 inch diagonal screen size.
5. Backlight Lamp: LED type.
6. Interface Type: 40 pin.
7. Suitable model: B101AW03 V.0 LTN101NT02 07 LP101WSA TLA1 CLAA101NB01.


Specification:
General
Model N101BGE-L21
Screen Size 10.1 inch
Screen Type LCD module, a-Si TFT-LCD
Resolution 1024 (RGB) x 600 (WSVGA)
Brightness (cd/m2) 200
Power Supply 3.3V
Connector LVD (1 ch, 6 bit), 40 pin, Terminal
Working Mode TN, Normal white display, Transmissive
Display Color 262k 45%(CIE1931)
Contrast Ratio 400:1
Viewing Angle 45/45/15/35(CR>=10)
Shape Style Thick screen (PCBA Bend, >=5.2mm)
Surface Matte
Backlight Type WLED, 10K hours, with LED diver
Response Speed 16 (Typ.) (Tr + Td) ms
View Size 224.72 x 127.28mm
Display Size 222.72 x 125.28mm
Size 24 x 14.3 x 0.5cm
Weight 185g
Package Weight
One Package Weight 1.15kgs / 2.54lb
One Package Size 45cm * 33cm * 8cm / 17.72inch * 12.99inch * 3.15inch
Qty per Carton 10
Carton Weight 12.50kgs / 27.56lb
Carton Size 62cm * 40cm * 30cm / 24.41inch * 15.75inch * 11.81inch
Loading Container 20GP: 358 cartons * 10 pcs = 3580 pcs
40HQ: 832 cartons * 10 pcs = 8320 pcs
